Wednesday, 20 September 2017

Pasta Machine Press - flatbed printer!

I had been using my pasta machine press successfully with monoprints in 2016, but after taking a print workshop in the spring of this year at the National Print Museum Dublin, my husband suggested it might be easier if I did some further adjustments on the pasta machine to turn it into a flatbed printer. This is the happy result, and below I will give some steps to converting a pasta machine into a small press!


My pasta machine had a base that was just screwed on, so it was easily removed.


 I planned to do some long prints, with the pasta machine on the kitchen table, so this was taken into account when creating a box structure that the machine could sit in. A box structure is required also to facilitate additional clamping to the table the press will rest on. This is a view of the finished flatbed printer including the 800 micron acetate which serves as a flatbed. Please note that the acetate is not affixed.


A bespoke groove is made into the top side of the box in order to facilitate the pasta machine.


This is the view from the right side of the machine, resting in the box structure. The hole on the side is where the crank fits in, so this side must be on the edge of the table.


This view primarily shows how the left side of the pasta machine is clamped to the wooden structure.



This is the press and structure turned on its side so that the under structure can be seen. The press is clamped to the structure.



This is a view from directly underneath the pasta machine.


A view from underneath; at either end there is a small plank of wood affixed to the structure to accommodate further clamps needed for affixing the structure to the table. At first I did not attach the structure to the table, but doing so saved me from having to press down on the machine while printing.


This picture is a side view that shows how the structure is attached to the table by a clamp.


This is a further detail view of the clamp attaching the slat on the structure to the table.


 This is a side view that shows how the 800 micron acetate serves as a flatbed.


I have found that oilcloth makes a good substitute for felt. It is cheap, has a heavier weight for its thin-ness than felt, and is more useful for me, in that I have been doing long prints and needed an unavailable size felt (two pieces of felt left a seam mark in my print!). Be sure to print smooth side up when using oilcloth to avoid any texture inadvertently appearing on your print.


I have tried to make these instructions as simple as possible, but please comment or message me if something is unclear. I have been doing intaglio prints and embossed prints using this machine, so it is working!

Wednesday, 13 September 2017

New notebooks - pouch binding - part 2

As I mentioned in last week's blog, I had decided to make some notebooks/sketchbooks from my Mum's handbags. I also mentioned that I had taken the Future Learn online course "Japanese Culture Through Rare Books" offered by Keio University and was inspired to make several pouch bound books, which utilised recycled paper. Last week's instructions were about preparing the pouches (i.e., creasing and folding paper such that the pre-used side was inside and the outer, clean layers would form the pages). This week is mostly about creating the covers, in this case a hard(ish) cover. The final binding is originally a Japanese technique - "stab binding" - which I have blogged about previously.

When I removed the lining from the purple handbag, I found that the underside of the vinyl had a fuzzy, kind of sticky, coating. My decision to use this for a hardcover was clear as I definitely didn't want this part of the handbag visible in my final book. I cut two pieces of vinyl to a size slightly larger than the cardboard base covers and clipped the corners. The pictures are mostly of the back cover, which does not have any bumpy surfaces.


I used an old plastic membership card to spread PVA glue over the entire surface of the vinyl underside.


The cardboard base was placed on the vinyl.


The vinyl was folded over the cardboard.


It was necessary to use lion clips to hold the folded vinyl down while the glue was drying.


A sheet of paper was cut to the size of the two covers plus the book spine (hold the pouches together tightly and measure the spine; in the case of pouch binding, it is the "open" side of the pouch, opposite the fold, which will be bound). Glue is first spread on the back cover. Again, an old plastic membership or bank card is ideal for spreading the glue.


The right side of the paper is gently pressed onto the cover.


The procedure is repeated for the front cover, making sure to let the far right side of the paper meet up with the far right side of the cover. The spine space between the two covers is apparent. Note that the front cover of my book is quite bumpy. I had to be careful not to rip the paper when adhering it because


 there were pleated and wired details on the original handbag that I wanted to keep on the bookcover.


I spread out the bookcover concoction and placed it between several clean pages, before weighing down with some heavy books until the glue dried completely (overnight at least).


Once the cover was dry I prepared everything for binding. I used some marbled origami paper for end papers. The lion clip is holding everything in place while I get ready.


Putting holes through the covers and folios is very important. I cannot stress this enough. For a book of this size (A5) five holes will do nicely. The lion clips are necessary to hold everything in place while the holes are being made and while the book is being sewn.


The sewing technique is Japanese stab binding. Make sure to make the holes large enough all the way through the layers (front cover, endpapers, folio-pouches, back cover) in order that you may sew through the same hole several times with your binding thread. Here I am using 3-strand cotton embroidery thread, folded so the first sew is 6 strands and the second sew is 12.


I cannot stress enough the importance of making the holes wide enough -- I ran into a problem with not being able to go beyond the initial 6 strands in the middle hole of my book. I didn't mind working with the idea of bypassing the hole since this is a personal book (not for a gift) and my first attempt at pouch binding as well as my first attempt at a hardcover book. However, for stability and security as well as for design, I think it is a better idea to ensure the hole is a good size to begin with!


The final book is sturdy and quirky. I like it!


Wednesday, 6 September 2017

New notebooks - pouch binding - Part 1

As soon as I received a bag of my Mum's old handbags, I had the idea that I would convert them into notebooks or sketchbooks. The handles on the bags are an interesting, decorative detail but I haven't decided yet whether they will be used in the final books.


 Earlier this year I took a free MOOC course offered by Keio University in Japan, through Future Learn. The course was called Japanese Culture Through Rare Books, and one of the styles of book-binding discussed was "pouch binding", which made great use of paper (rare in ancient Japan) that was already used on one side. Having a great supply of paper to recycle I decided that I would try pouch binding for my handbag books. On a historical note, pouch bound books give historians great insights into a period when a book is un-bound for conservation purposes: the original information on the paper is intact!


To reiterate: the used paper should be completely blank on one side. This is what will be visible in the final books.


 After cutting the A4 pages in half my trusty bone folder was used to fold the now A5 pages in half, the used side in, such that blank pages are what is visible.


I stacked my folios in piles of 10 for ease of keeping track of the count. In pouch binding it is the folded part of the book that is the turning part of the page, while the "open" long side of the pouch page is bound as the book spine.


Before continuing with the binding of pages, I had to cut up the bags. I want these to be hard cover books so I also cut some corrugated cardboard to a size slightly larger than the folios.



Wednesday, 30 August 2017

Picasso Museum Antibes

A visit to Antibes usually affords me the luxury of a walk through the old town to Chateau Grimaldi, the home of the Musée Picasso. It is a beautiful building, sufficiently small enough to allow for a visit in less than half a day, sufficiently large enough to be satisfied with that visit.


I have been to the museum often enough to know whose work in the permanent collection I want to make a beeline for. The first floor rooms contain the work of husband and wife artists Hans Hartung and Anna-Eva Bergman. I pay my respects to Hartung's abstractions, but it is Bergman's work that I muse over. I love her use of gold and other metal leaf in her works.



Before having a detailed look at the current exhibition of Picasso photographs by Irish photographer Edward Quinn (a quick google search will provide plenty of images), I visit my ultimate favourite painting in the museum. I have featured Nicolas de Stael's Le Concert in a previous blog, but it is always worth looking at again. Unlike de Stael's other large painting in the museum, Le Concert is not a heavily impastoed painting and I actually came across a reference to it being unfinished. It may have been his last large painting and I think it is gorgeous. I love it.


On the opposite wall to Le Concert, was a smaller de Stael painting that I had not taken particular note of in previous years. The painting is of Fort Carré and as I passed de Stael's former residence on the coast on my way to the museum, I know it is a view from his Antibes home. I have never seen the fort on a grey day, so I have the feeling it was painted in winter. (Though my first visit to Antibes many years ago was at the end of December and it was quite sunny and warm!)


On the outdoor terrace overlooking the Mediterranean a number of large sculptures are installed. I particularly love the bronze La Grande Spirale by Germaine Richier. There are a number of Richier's familiar figure sculptures on the wall of the terrace, but it is this piece, reminiscent of a broken seashell that attracts me.



Wednesday, 16 August 2017

Ceramic workshop

As previously mentioned, I have been participating in a ceramics workshop at Signal Arts Centre. The workshops are held in periods of six weeks, and during the second round of workshops I was working on the book covers but also brushing up on the coil hand-building technique. I decided to make a set of four round coasters and since I had a bag of coloured glass blobs, I thought I would incorporate them into the design.


After making the coil coasters I scooped out their centres creating a divet to hold a glass blob each. I decided on the colours: blue, red, mauve and yellow. I glazed each coaster with "burnt sugar" glaze, which I then used a damp sponge to wipe. The red and the blue blobs melted perfectly on their coasters, but the mauve seemed harder to melt and has a cracked glass appearance. I imagine that the yellow blob must have reacted to the glaze as it appears more red (it is the one at the top) and it didn't melt evenly.


I also made a coil cylinder, most likely to be used as a pencil holder. I glazed the outside with "burnt sugar" and again used a sponge to wipe it. The inside was glazed with a clear glaze.


Some years ago I was commissioned to do a stained glass piece for Enniscorthy Community Hospital, and I had some beautiful coloured glass left over. I brought a small compartmentalised storage box of glass bits to the ceramics workshop to use and share with the others in the group. Though the picture below shows only four compartments, there are actually 21 in the box, each containing a different colour or type of glass.


I added a few pieces of an irridescent green to the bottom of the coil pencil holder and it melted quite nicely!

Wednesday, 9 August 2017

The Key - bound

As I said in last week's post, I have been taking a ceramics workshop on Thursday afternoons at Signal Arts Centre, and had the idea to test the possibility of a ceramic book cover. I made these two piecces as back and front covers of a book with a "stick book" binding.


I decided to make a personal, unique book of key images on handmade paper. so prepared the individual pages for the book before starting any drawings.


On the back inside cover I used PVA glue to affix a strip of paper as an information page.


This shows the covers' relationship to each other prior to inserting the pages.


I wrapped a thinner piece of acid-free rag paper around the pages, holding them together with lion clips before using an awl to create holes.


The covers and pages are ready to put together.


Quite thin garden wire, which is covered with PVA, is threaded through the holes to bind the book.


The book is a sturdy little thing! My name is stamped on the back cover: this was done prior to firing when I first created the cover in clay.


My hand shows the intimate scale of The Key.


The inside back cover gives information details: title, materials, edition, date and signature.
